Animation

8. Animation

Animation in computer graphics is the controlled change of images over time to create the illusion of motion. The human visual system perceives continuous motion when a sequence of still images is shown rapidly (typically ≥ 24 frames per second). Each frame is static; motion exists only in the viewer’s brain.

What is the minimum frame rate required for the human eye to perceive smooth motion?

A: Typically 24 frames per second (fps) or higher. Below this, the brain may perceive flicker rather than continuous motion.

8.1 Illusion of Motion – Core Concept

Animation exploits persistence of vision and temporal coherence. Small, consistent changes between consecutive frames are interpreted as smooth movement.

Frame: A single still image.
Frame rate: Number of frames shown per second.
Temporal continuity: Objects move slightly, not randomly, between frames.

Without continuity, the brain detects flicker instead of motion.

            flowchart TD
                Input[User Input / Script] --> Update[Update State]
                Update --> Physics[Apply Physics/Rules]
                Physics --> Render[Render Frame]
                Render --> Display[Display on Screen]
                Display --> Wait[Wait for next frame]
                Wait --> Update

Which two psychological/physiological concepts make animation possible?

A: Persistence of Vision (retraining an image for a split second) and Temporal Coherence (small changes interpreted as movement).

8.2 Key Techniques in Animation

8.2.1 Keyframing (Start / End Poses)

Keyframes define important states (poses) of an object at specific times. The animator specifies what matters, not every frame.

Pose: Position, rotation, scale, shape, or color at a given time. (See Transformations)
Time index: When that pose occurs.

Example: A ball at rest (t=0), ball at peak height (t=1), ball on ground (t=2).

In keyframing, what does the animator define versus what the computer calculates?

A: The animator defines the Keyframes (start/end poses at specific times). The computer calculates the in-between frames.

8.2.2 Tweening (In-betweening)

Tweening automatically generates intermediate frames between keyframes to create smooth motion.

Conceptually, the computer fills the gap between two known states.

For position interpolation:

$$P(t) = P_0 + t(P_1 - P_0), \quad 0 \le t \le 1$$

P₀: Start position
P₁: End position
t: Normalized time

What is the linear interpolation formula for position $P(t)$?

A: $P(t) = P_0 + t(P_1 - P_0)$, where $t$ ranges from 0 to 1.

8.2.3 Interpolation

Interpolation is the mathematical foundation of tweening. It computes intermediate values between known values.

Linear interpolation (LERP): Constant speed
Non-linear interpolation: Acceleration / deceleration (ease-in, ease-out)

Interpolation applies to:

Position
Rotation
Scale
Color
Shape parameters

How does Non-linear interpolation differ from Linear interpolation in terms of motion feel?

A: Linear is constant speed (robotic). Non-linear allows for acceleration and deceleration (ease-in/ease-out), making motion feel natural.

8.2.4 Morphing (Shape Transformation)

Morphing smoothly transforms one shape into another by interpolating corresponding points.

Key idea: establish point-to-point correspondence between source and target shapes.

Used in face transformation, logo animation, special effects
Avoids abrupt shape changes

Morphing is advanced tweening applied to geometry, not just position.

What is the most critical step in setting up a Morphing animation?

A: Establishing point-to-point correspondence between the source and target shapes to ensure a smooth transition without distortion.

8.2.5 Panning (Camera Movement)

Panning is camera motion where the camera moves horizontally or vertically while observing a scene.

The objects do not move; the viewpoint moves.

Common in 2D side-scrollers and 3D games
Guides viewer attention
Enhances spatial understanding

In computer graphics Panning, does the scene move or the camera?

A: Technically, the Viewpoint (Camera) moves. The objects in the scene remain stationary in world coordinates.

8.3 Types of Animation

8.3.1 Frame-by-Frame (Traditional Animation)

Each frame is drawn manually.

Maximum artistic control
High cost and effort
Used in classic hand-drawn animation

No automation; motion quality depends entirely on the animator.

Why is Frame-by-Frame animation rarely used for complex 3D scenes today?

A: It requires extremely high effort and cost since every single frame must be created manually.

8.3.2 Keyframe Animation

Only key poses are defined manually; intermediate frames are generated automatically.

Efficient
Widely used in modern animation tools
Depends on interpolation quality

What makes Keyframe Animation efficient?

A: Animators only create the significant poses (Keyframes); the computer automates the rest.

8.3.3 Procedural Animation (Rules / Math-Based)

Motion is generated using mathematical formulas or algorithms.

No predefined frames
Motion emerges from rules

Example: Oscillating motion

$$y(t) = A \sin(\omega t)$$

Used in waves, fire, crowd motion, environment effects.

How does Procedural Animation differ from Keyframing?

A: Procedural uses mathematical formulas/rules (e.g., sine waves for water) to generate motion, rather than manual poses.

8.3.4 Behavioral Animation (AI / Rule-Based)

Objects decide how to move based on rules, goals, or environment.

Common in games and simulations
Uses artificial intelligence concepts

Example: A character avoids obstacles while moving toward a target.

What drives motion in Behavioral Animation?

A: Rules or AI governing interactions (e.g., "avoid obstacles", "follow the leader").

8.3.5 Motion Capture (MoCap)

Real human motion is recorded and mapped onto digital characters.

High realism
Used in films and AAA games
Requires sensors and cleanup

Transforms physical motion data into animation parameters.

What is the primary advantage of Motion Capture (MoCap)?

A: It captures nuanced, realistic human movement that is very difficult to animate manually.

8.3.6 Dynamics Animation (Physics-Based)

Motion is governed by physical laws.

Based on Newton’s laws:

$$F = m a$$

Gravity
Collisions
Forces and constraints

Used in falling objects, cloth, fluids, rigid-body simulations.

If you wanted to simulate a falling rock, which animation type would you use?

A: Dynamics Animation (Physics-based), utilizing gravity and collision laws ($F=ma$).

Animation Dynamics

Animation: Illusion of motion created by rapid sequence of still frames; relies on Persistence of Vision.
Keyframing: Defining only the start and end poses (important states) manually at specific time indices.
Tweening (In-betweening): Automatic generation of intermediate frames between keyframes using interpolation.
Interpolation: Mathematical calculation of values (position, rotation, color) for intermediate frames (Linear vs. Non-linear/Ease-in-out).
Morphing: Smooth transformation of one shape into another by establishing point-to-point correspondence.
Procedural Animation: Motion generated by algorithms/math rules (e.g., waves, fire) rather than manual keyframes.
Dynamics: Physics-based animation using laws of motion ($F=ma$) for gravity, collisions, and cloth simulation.
